2 - 1
2.1 Overall Configuration
2. SYSTEM CONFIGURATION
2.1 Overall Configuration
The overall configuration of GOT is as follows.
For the connection methods applicable to GOT1000 series and cable, refer to the following.
GOT1000 Series Connection Manual
• GT11 does not connect a printer.
Bar code reader
Commercially available
Option function board
CF card
GOT
Personal computer
Commercially available
Memory card
CF card Memory card adaptor
Protective sheet
Stand
GRAPHIC OPERATION TERMINAL
GOT
1000
MITSUBISHI

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mitsubishi GOT1000 GT11 and is the answer not in the manual?

Mitsubishi GOT1000 GT11 Specifications

General IconGeneral
Power Supply24V DC
Operating Temperature0 to 50°C
Storage Temperature-20 to 60°C
Screen Size5.7 inches
Resolution320 x 240 pixels
Communication InterfaceRS-422/485, USB
MemoryInternal flash memory
CPURISC
Touch PanelAnalog Resistive
