13 - 8
13.2 OS Information
13.2.3 Display example of OS information
9
UTILITY FUNCTION
10
COMMUNICATION
INTERFACE
SETTING
11
DISPLAY AND
OPERATION
SETTINGS
12
CLOCK SETTINGS
AND BATTERY
STATUS DISPLAY
13
FILE DISPLAY AND
COPY
14
GOT SELF CHECK
15
CLEANING OF
DISPLAY SECTION
16
INSTALLATION OF
BOOTOS AND
STANDARD MONITOR OS
13.2.3 Display example of OS information
Remark
Displayed folders and files
Refer to the following for the details of displayed folders and files.
Section 13.1.4 Display file
Number Item Contents
(1) Select drive
The drive of which file or folder is displayed can be selected. When the CF card is
not installed, [A: Built-in CF card] will not be displayed.
(2) Kind
Indicates whether the displayed name is for file or folder.
In case of file, displays the extension; in case of folder, displays "DIR".
(3) Name
The file name or folder name which is stored in the selected drive or folder is
displayed.
When the file name or folder name exceeds 20 characters, the exceeding
characters (the 21th character or after) are not displayed.
(4) Path name The path name of the currently displayed drive/folder is displayed.
(5) Size Displays the size of the file displayed in Name.
(6) Date and time The date and time when each file was installed are displayed.
(7) The size of drive Displays the size in use size of the drive which is selected by drive selection.
(8) Operation switch
Execution switch of each function (install, upload, etc.) which can be executed on
the OS information screen.
(9) Number of files Displays the total number of the displayed files.
OS information screen: Storage file/folder display screen
(2)
OS information screen
(1)
(3)
(4)
(5) (6)
(7) (8) (9)
To Next Page
