Mitsubishi GOT1000 GT11 User Manual

3 - 3
3.2 Performance Specifications
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
PART NAME
5
EMC DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
• GT1155-QTBDQ, GT1155-QSBDQ, GT1150-QLBDQ, GT1155-QTBDA,
GT1155-QSBDA, GT1150-QLBDA
Item
Specifications
GT1155-QTBDQ
GT1155-QTBDA
GT1155-QSBDQ
GT1155-QSBDA
GT1150-QLBDQ
GT1150-QLBDA
Display
section
*1
Type TFT color liquid crystal Color liquid crystal
STN monochrome (black/
white) liquid crystal
Screen size 5.7"
Resolution
320 240 dots
Display size
W115(4.53) H86 (3.39)[mm](inch) (Horizontal format)
Display character
16-dot standard font: 20 characters 15 lines, 12-dot standard font: 26 characters
20 lines (Horizontal format)
Display color 256 colors
Monochrome (black/white),
16 scales
Display angle
Left/right: 70 degrees, Top:
70 degrees, Bottom: 50
degrees (Horizontal format)
Left/right: 55 degrees, Top:
65 degrees, Bottom: 70
degrees (Horizontal format)
Left/right: 45 degrees, Top:
20 degrees, Bottom: 40
degrees (Horizontal format)
Contrast adjustment - 16-level adjustment
Intensity of LCD
only
400[cd/m
2
]
(Adjustable in 8 levels)
380[cd/m
2
]
(Adjustable in 8 levels)
220[cd/m
2
]
(Adjustable in 8 levels)
Intensity adjustment 8-level adjustment
Life
*2
Approx. 50,000 h (at operating ambient temperature of 25 )
Backlight
Cold cathode fluorescent tube (irreplaceable by the user) backlight detection function is
included
Backlight/screen saving time can be set.
Life
Approx. 75,000 hours or longer. (The time takes to
reduce to 50% of the backlight luminance at the operating
ambient temperature of 25 )
Guaranteed: 1 year
Approx. 54,000 hours or
longer. (The time takes to
reduce to 50% of the
backlight luminance at the
operating ambient
temperature of 25 )
Guaranteed: 1 year
Touch
panel
Number of touch
keys
300 keys/screen (Matrix of 15 lines 20 columns)
Key size
Minimum 16 16 dots (per key)
Maximum
simultaneous key
presses
Maximum of 2 points
Life 1 million times or more (operating force 0.98N max.)
Memory
C drive
*3
Flash memory (Internal), for storing project data (3Mbytes) and OS
Life (Number of
write times)
100,000 times
D drive SRAM (internal), 512kbytes (battery backup)
Battery GT11-50BAT lithium battery
Backup target Clock data, alarm history and recipe data
Life
Approx. 5 years (Operating ambient temperature of 25 ), Guaranteed: 1 year
Buzzer output Single tone (tone length adjustable)
Environmental protective
structure
*4
Equivalent to IP67f (JEM1030) (front section) when the USB environmental protective
cover is attached (Horizontal format)

Mitsubishi GOT1000 GT11 Specifications

General

Power Supply	24V DC
Operating Temperature	0 to 50°C
Storage Temperature	-20 to 60°C
Screen Size	5.7 inches
Resolution	320 x 240 pixels
Communication Interface	RS-422/485, USB
Memory	Internal flash memory
CPU	RISC
Touch Panel	Analog Resistive
