13 - 18
13.3 Project Information
13.3.4 Operation of project information
9
UTILITY FUNCTION
10
COMMUNICATION
INTERFACE
SETTING
11
DISPLAY AND
OPERATION
SETTINGS
12
CLOCK SETTINGS
AND BATTERY
STATUS DISPLAY
13
FILE DISPLAY AND
COPY
14
GOT SELF CHECK
15
CLEANING OF
DISPLAY SECTION
16
INSTALLATION OF
BOOTOS AND
STANDARD MONITOR OS
3 Copy operation
The file in the A drive is copied to another directory of the A drive.
Copy to/from C drive or D drive is disabled.
1 Install CF card in the PC, in which create a
folder for the copy destination.
Set the same character with [System
Setting] of [System Environment] of GT
Designer2 for the folder name.
GT Designer2 Version Screen
Design Manual
(Section 3.1 GOT/PLC Type Setting)
2 Install the CF card mentioned above to
GOT.
Refer to the following for inserting/
removing method of CF card.
Section 8.1 CF Card
3 Open [Project information] and touch the
drive of the file to be copied to select the
drive, and then touch the button.
The dialog for selecting a copy destination
folder as shown left is displayed.
4 Touch the folder display area to select a
folder, and then touch the button.
The dialog shown left is displayed.
Dialog for selecting a copy destination drive
Dialog for selecting a copy destination folder
Next
Exec.
To Next Page
