Mitsubishi GOT1000 GT11 - Page 172

14 - 10
14.4 Drawing Check
14.4.3 Display and operation of drawing check
2 Basic figure check
Check whether there is no shape transformation of basic figure or display losses.
The basic figure drawn has 4 types: 1. Filled circle, 2. Line, 3. Rectangle, 4. Ellipse.
To (a) Pattern 1 of
Move check among screens
