14 - 12
14.4 Drawing Check
14.4.3 Display and operation of drawing check
(c) Pattern 3: Shape transformation, color check
The overlaped shapes of pattern 1 and pattern 2 are displayed.
If the shape and color (white, yellow, light blue, green, purple, red, blue, black) are displayed
visually in order, it is normal.
For GT1150 (monochrome 16 scales), each color is subtracted to monochrome 16-scale.
(d) Pattern 4: Shape Check
The drawn figures are displayed in order and at regular intervals.
If the shape and color are displayed visually in order, it is normal.
If touch the upper right part of the screen, returns to [Display check] screen.
To Pattern 4
To [Display check]
