SETUP
© 2014 Mold-Masters (2007) Limited. All Rights Reserved.
Revised 1 Oct, 2014
5-10
www.moldmasters.com
Function Description Setting Limits
Alarms Active Offers a selection table which allows
you to decide how any of the following
alarm conditions should affect the
system:
- High Temperature Alarm
- Low Temperature Aarm
- Zone Alarm
- Power Alarm
Options for Alarm actions are:
Console - which displays the alarm
condition in the lower Status Panel.
Beacon - extends the alarm to activate
an attached Alarm Beacon and Sounder.
Mould Protect - puts the console into
Stop Mode. All zone heaters will , as a
result, cool down.
Injection Disable - sends out a shut-
down signal from the IO Card which
may be externally congured to stop the
moulding machine.
Alarm Time
(seconds)
Congure a brief delay between an
alarm condition being detected, and an
external alarm being sent.
The maximum setting for Alarm Time is
999 seconds.
Maximum Set-
point Setting
Sets the highest permitted set-point for
the zone(s).
The highest Maximum Set-point
temperature that you can set is 450°C or
850°F.
Minimum Set-
point Setting
Sets the lowest permitted set-point for
the zone(s).
The lowest Minimum Set-point
temperature that you can set is 0°C or
0°F.
Maximum
Power Setting
Sets the highest permitted power
level for the zone(s). This will work in
either open loop (Auto) or closed loop
(Manual) conguration. However, it is
not effective for 4MODS cards working
Seki-Spear probes.
The highest Maximum Power Setting that
you can set is 100% power.
T/C Offset
Value
Sets a proportional offset between
measured and displayed temperature
to compensate for a probe where the
T/C may not be sufciently close to the
tip.
The highest T/C Offset temperature is
±75°C or ±135°F.
Speed Select, or over-ride, the Auto-
Speed setting to determine the
control characteristic for the zone
temperature.
Note: The Ultra settings force the
controller to stay in phase angle ring
all the time. These settings are used
where a very small nozzle could show
temperature instability in burst red
mode.
Sensor Select temperature sensor for the
zone(s) (J or K type) for Heater Control
cards or Analogue sensors for AI
cards. Analogue sensors read 0-20 mA
and may be used for ow, pressure or
other device.
The Tool Parameters - contd.
