SETUP
© 2014 Mold-Masters (2007) Limited. All Rights Reserved.
Revised 1 Oct, 2014
5-11
www.moldmasters.com
Function Description Setting Limits
Display Group Select groups of zones to display on
separate Display Pages.
By default all zones are in group 1 but
selected zones can be allocated to
subsequent groups.
Zones that need not be shown on
the Display page can be allocated to
Display Group Zero.
There is a limit of 6 Display Groups.
Startup Stage Congure groups of zones into
discrete Startup Groups.
There is a limit of 6 Startup Groups.
Shutdown
Stage
Congure groups of zones into
discrete Shutdown Groups.
There is a limit of 6 Shutdown Groups.
Readings Avg
(for Analogue
Input Cards)
Can be used to smooth out analog
input display where the sensor may
send uctuating readings. The drop-
down list is the number of readings
that are read to generate an overall
average.
Available setting options are 0, 2, 4, 8, 16
or 32.
NOTE - This parameter only appears if
an Flow Monitor (Analogue Input) card is
detected in the rack.
(The following 4 parameters appear only if a spear card is detected)
Pre-Heat Sets the power level for the spear
body.
Boost Sets the power level required to open
the tip.
Delay Sets a delay following the signal to
inject until the Boost “opening” power
is applied.
Time Sets the “Gate-open “period for
applying tip power.
The Tool Parameters - contd.
