SETUP
© 2014 Mold-Masters (2007) Limited. All Rights Reserved.
Revised 1 Oct, 2014
5-14
The Tool Settings - contd.
Function Description Limits
Input Signal
(this comes
from the
HAN4A
auxiliary input
at the rear of
the cabinet)
Set how the console responds to a remote input
(normally open pair):
STANDBY If Closed - switches the controller into
Standby mode when the remote input is closed;
and returns to its previous state when the signal is
removed.
STANDBY If Opened - switches the controller into
Standby mode when the remote input is opened;
and returns to its previous state when the signal is
restored.
BOOST if Closed - this switches the controller into
boost mode when the remote line is closed.
STOP if Closed - switches the controller into Stop
mode when the remote line is closed.
STOP if Opened - switches the controller into Stop
mode when the remote line is opened.
NOTE:
1. The remote input is only
effective when the system
is in RUN mode.
2. This function defaults to
BOOST when the controller
has Spear zones.
3. Only those zones that
have Boost or Standby
temperatures congured in
their SetUp will respond to
the remote input signal.
Power Mode Selects how power levels are shown on the Display
Page.
Percentage power is constantly displayed while you
have an option on what is seen in the lower window.
If you have control cards with current measuring coils
this option allows the lower window of each zone to
show three possible parameters.
Choose [
Amperes] to show the zone current.
Choose [
Watts] (provided the supply voltage has
been set) to show the power in the zone.
If there are no current measuring coils then the lower
window display will be blank.
Choose [
Ohms] (provided the supply voltage has
been set) to show the calculated resistance value for
that zone.
Power Alarm
Delay
Allows you to pause the Power Alarm by this many
minutes so it does not instantly cause an alarm effect.
Defaults to Zero minutes
delay.
Pressure
Units
Select whether to quantify the Pressure Zones in Bar
or PSI.
Purge Mode
Choose [
Mechanical] (which uses heat steps
only) or [Chemical] (to work with special purge
compounds).
Quad IO
Reset Time
This is a timer within the IO Card. The timer will set
all relay outputs to off (de-energised) if it fails to see
communication with the Console within this set time.
The default setting is “0” in which case it will not look
for incoming signals and operate normally.
Maximum Reset time is 90
seconds.
NOTE- This parameter only
appears if an IO card is
detected in the rack.
To Next Page
