SETUP
© 2014 Mold-Masters (2007) Limited. All Rights Reserved.
Revised 1 Oct, 2014
5-15
Function Description Limits
Second
Startup
Select a nal operating mode that the console
assumes once it has completed a Startup Sequence
and attained normal temperature.
[
RUN] is default condition.
[
BOOST] will temporarily assume boost settings until
it times out.
[
STANDBY] will reduce to Standby Temperature
until it is manually or remotely changed.
Stage Soak
Timer
If Staged Startup is selected then this option allows
you to congure a set time for each stage to hold or
soak before the next stage is initialised.
You may set a different time for each of the stages
that you create.
During Startup, while a Stage is held for its soak
period, then the Mode Window display, at the
bottom of the screen, changes from “STARTUP”
to an message that switches between “SOAK” and
“STAGE1, 2, 3 etc.” until all stages reach working
temperature, when it changes to “RUN”.
Defaults to zero minutes so
no soak time is introduced
unless selected here.
This option will only be
available if you select
“Stage Startup” as an
option in Startup Mode.
Soak Timer Set a time here to force the console to hold in Soak
mode, at the end of a startup option, before it switches
automatically to Run.
This can be used to insert extra pause, or a period of
temperature balancing, before the console switches to
“run” and sends an Injection Enable signal to the rest
of the machinery.
The Status bar will display SOAK in the Mode box
during this time.
Also a QuadIO output called Soaking has been added
which is active during the Soak time.
Standby
Temp
Set an overall standby temp which will override
individual standby temperature settings that may be
congured within the earlier Tool parameters.
Leave this set to 0° for individual standby values to
remain valid.
Max standby Temp is
260°C.
To Next Page
