Issue 2.0

4-70 Features and Specifications

RELATED FEATURE LIST

 Station-to-Station Calling – K-CCIS

GUIDE TO FEATURE PROGRAMMING

This guide provides a list of associated Programs that support this feature.

Program/

Item No.

Description/Selection Assigned Data Comments

20-13-36 Class of Service Options

(Supplementary Service) –

Call Duration Timer Display

0 = Off

1 = On

Default is 1

Turn off the extension Call Timer. The system

waits for the interdigit time (21-01-01) before this

time begins.

20-09-06 Class of Service Options

(Incoming Call Service) –

Incoming Time Display

0 = Off

1 = On

Default is 0

Turn on the Incoming Time and Date display on the

LCD while the Telephone is ringing.
