Issue 2.0

5-42 SV9100 IP K-CCIS

SECTION 4 PORT DESIGNATIONS

This section provides port number designations for IP applications.

Program 50-02-02

1. Select CCIS Route ID

2. Assign Data Speed LK

2 (56k)

Program 50-02-01

1. Select CCIS Route ID 1

2. Assign Channel Port

Program 50-02-02

1. Select CCIS Route ID 1

2. Assign Data Speed LK

2 (56k)

Program 50-02-03

Route ID 9 : 2

Program 50-03-01

1. System ID 1 : 3

2. System ID 2 : 4

 For CCISoIP only

System A System B System C

IP Application IP Port Numbers Comments

SIP Trunk

SIP Trunk Signaling 5060 UDP

SIP Trunk Voice with GPZ-IPLE 10020~10531 UDP

3rd Party SIP

SIP SLT Signaling 5070 UDP

SIP SLT Voice with GPZ-IPLE 10020~10531 UDP

H.323 Trunk

H.323 Signaling 1718/1719/1720 TCP

H.323 Trunk Voice with GPZ-IPLE 10020~10531 UDP
