NEC Univerge SV9100

Issue 2.0
5-24 SV9100 IP K-CCIS
2.5 Open Numbering Plan – Using ARS Table 1, 2, or 3
Use these programs to assign system numbering, ARS/F-Route dialed digits and
trunk groups as well as other ARS/F-Route table information for an Open
Numbering Plan.
44-02-03
Dial Analysis Table for
ARS/F-Route Access –
Additional Data
2 = 0~500
0 = No Setting
Default is 0
When setting data is (2), refer
to Program 44-05.
44-05-01
ARS/F-Route Table –
Trunk Group Number
0-100,101-150,255
0 = Not Set
1~100 = Trunk Group from
PRG 14-05
101~150 = Networking
255 = Extension Call
Default is 0
Select the trunk group used for
the outgoing K-CCIS call.
Table 5-11 Open Numbering Plan Assignments
Program
/Item No.
Description/Selection Assigned Data Comments
11-01-01
System Numbering
2 = Extension Number Defaults for 1X, 2X, 3X = 2
Extension Number.
44-02-01
Dial Analysis Table for
ARS/F-Route Access –
Number of digits to be
analyzed by the system
Up to 8 digits can be
assigned.
Use line key 1 for Don’t Care
digit, @
Default is No Setting
Assign the digits to be dialed
across the K-CCIS link. These
digits were assigned as F-Route in
Program 11-01-01.
44-02-02
Dial Analysis Table for
ARS/F-Route Access –
Service Type
2 = ARS/F-Route Table
(F-Route)
Default is 0
The service type (2) assigns the
digits to be dialed to an F-Route.
Program 44-02-03 assigns the
F-Route to be used.
44-02-03
Dial Analysis Table for
ARS/F-Route Access –
Additional Data
0~500
(0 = No Setting)
Default is 0
When setting data is (2), refer to
Program 44-05.
Table 5-10 Closed Numbering Plan Assignments (Continued)
Program/
Item No.
Description/Selection Assigned Data Comments
