Issue 2.0

8-18 IP Multiline Station (SIP)

10. When the Save window opens, click Save as...

11. In the Save As window, name the file xxx.gz.

Example: To name the file test, enter test.gz

12. Place this file in the FTP server.

Figure 8-12 Save As/Name File Window
