NEC Univerge SV9100

Issue 2.0
SV9100 Networking Manual 5-23
2.3 Local Numbering Plan Assignment
Use these programs to assign system, extension and virtual extension numbering
for the Local Numbering Plan.
2.4 Closed Numbering Plan – Using Closed Number Blocks
Use these programs to assign system numbering and ARS/F-Route dialed digits
for a Closed Numbering Plan.
Table 5-9 Local Numbering Plan Assignments
Program/
Item No.
Description/Selection Assigned Data Comments
11-01-01
System Numbering
0 = Not Used
1 = Service Code
2 = Extension Number
3 = Trunk Access
4 = Special Trunk Access
5 = Operator Access
6 = Flexible Routing
7 = Not Used
8 = Networking System
Access
9 = Dial Extension Analyze
Defaults for 1X, 2X, 3X = 2
Extension Number.
11-02-01
Extension Numbering
Assign Station Numbers to
Port Numbers
Defaults for Ports
Port 1 ~ 99 = 101 ~ 199
Port 100 ~ 960 = 3101 ~ 3961
11-04-01
Virtual Extension
Numbering
Assign Station Numbers to
Port Numbers
Defaults for Ports
Ports 1 ~ 99 = 201 ~ 299
Ports 100 ~ 512 = No setting
Table 5-10 Closed Numbering Plan Assignments
Program/
Item No.
Description/Selection Assigned Data Comments
11-01-01
System Numbering
2 = Extension Number Defaults for 1X, 2X, 3X = 2
Extension Number.
44-02-01
Dial Analysis Table for
ARS/F-Route Access –
Dial
Number of digits to be
analyzed by the system
Up to 8 digits can be assigned.
Use line key 1 for Don’t Care
digit, @
Default is No Setting
Assign the digits to be dialed
across the K-CCIS link. These
digits were assigned as
F-Route in Program 11-01-01.
44-02-02
Dial Analysis Table for
ARS/F-Route Access –
Service Type
2 = ARS/F-Route Table
(F-Route)
Default is No Setting
The service type 2 assigns the
digits to be dialed to an
F-Route.
Program 44-02-03 assigns the
F-Route to be used.
