Issue 2.0

SV9100 Networking Manual 4-5

 Internal Calls, transferred calls, and K-CCIS calls do not provide Caller ID to

single line telephones.

 Caller ID Call Return feature is not supported with K-CCIS calls.

SECTION 4 RELATED FEATURE LIST

 T1 Connections

 Universal Slots

SECTION 5 K-CCIS FEATURES

The remainder of this chapter provides detailed information for the available K-CCIS

features.
