3.11 Department Calling
Department Group access is available via Networking. When the extension at System A tries to make a
Department Call to System B, System A should have a numbering plan which defines the Department
Access code at System-B (must be defined as dial type 8, Networking in Program 11-01: System Number-
ing).
The following Department Calling options are supported with the Networking feature.
Operation
1. When dialing the Department access code for the networked system, the call is dialed in the same way
as normal.
2. A Department Call from the outgoing system will be routed to an available extension in the Department
Group.
Related Programs
Program Number Mode Same as Single System
16-01-02 Department Calling Cycle Yes
16-01-03 Department Routing When Busy Yes
16-01-04 Hunting Mode No
16-01-05 All Ring Mode When a call is transferred to a Depart-
ment Group with All Ring, there is a
difference in operation. In a single sys-
tem, an extension within the same sys-
tem can transfer a call to a Department
Group and the call will ring an exten-
sion within the Department Group once
the transferring user hangs up. In a net-
worked system, the transfer will not go
through and the call will recall the
extension performing the transfer.
16-01-06 STG Withdraw Mode No
16-01-07 Call Recall Restriction for STG No
16-01-08 Maximum Queuing Number No
16-01-10 Enhanced Hunting Mode No
Program Number Title
11-07-01 Department Group Pilot Numbers
16-01 Department Group Basic Data Setup
16-02-01 Department Group Assignment for Extensions
22-07-01 DIL Assignment
22-11-02 DDI
