Issue 2.0

SV9100 Networking Manual 5-33

Conditions

 The system must be reset for these program options to take affect.

Feature Cross Reference

 Voice Over Internet Protocol (VoIP)

SECTION 8 PORT DESIGNATIONS

The following lists the port numbers for supported IP applications.

Priority (D.S.C.P. -

Differentiated Services

Code Point)

0~63

DSCP (Differentiated

Services Code Point)

Item

No.

Item Input Data Default Description

Table 5-7 Port Designations for IP Applications

IP Application IP Port Numbers Comments

SIP Trunk

SIP Trunk Signaling 5060 UDP

SIP Trunk Voice with GPZ-IPLE 10020~10531 UDP

3rd Party SIP

SIP SLT Signaling 5070 UDP

SIP SLT Voice with GPZ-IPLE 10020~10531 UDP

H.323 Trunk

H.323 Signaling 1718/1719/1720 TCP

H.323 Trunk Voice with GPZ-IPLE 10020~10536 UDP

SV9100 IP - K-CCIS

IP K-CCIS Signaling 57000/5900 TCP
