NEC Univerge SV9100

Issue 2.0
SV9100 Networking Manual 5-33
3.1.1 Card Interface Slot Assignment (PRG 10-03)
The following slot assignments were set using program 10-03.
3.1.2 Digital Trunk Assignments
This example shows digital trunk assignments made for systems A and B.
Slot
Card Type During 1st
Power On
CARD TYPE AND PORTS
System A System B
Card Type Ports Card Type Ports
1
GCD-CP10/GPZ-IPLE GCD-CP10/GPZ-IPLE Trunks 5 ~ 28 GCD-CP10/GPZ-IPLE Trunks 5 ~ 28
2
GCD-8DLCA GCD-8DLCA Station 1 ~ 8 GCD-8DLCA Station 1 ~ 8
3
GCD-8DLCA GCD-8DLCA Station 9 ~ 16 GCD-8DLCA Station 9 ~ 16
4
None None N/A None N/A
5
GCD-4COTC GCD-4COTC Trunks 1 ~ 4 GCD-4COTC Trunks 1 ~ 4
6
None None N/A None N/A
System A System B
Program 10-03-01
Insert GPZ-IPLE on GCD-CP10 in Chassis 1, Slot
1.
Verify PRG 10-03-01 (ETU Setup)
Program 10-03-01
Insert GPZ-IPLE on GCD-CP10 in Chassis 1,
Slot 1.
Verify PRG 10-03-01 (ETU Setup).
Program 10-19-01
Assign DSP Resources 001~024 as CCIS (LK4).
Program 10-19-01
Assign DSP Resources 001 ~ 024 as CCIS
(LK4).
Program 10-68-01
Assign the Trunk Type as CCIS
Program 10-68-01
Assign the Trunk Type as CCIS
Program 10-68-02
Assign the Start Port as 5
Program 10-68-02
Assign the Start Port as 5
Program 10-68-03
Assign 24 as number of ports
Program 10-68-03
Assign 24 as number of ports
Program 14-05-01
Assign Trunks 5 ~ 28 in Trunk Group 10
Program 14-05-01
Assign Trunks 5 ~ 28 in Trunk Group 10.
Program 22-02-01
Set Trunks 5 ~ 28 as Tie Line (LK6).
Program 22-02-01
Set Trunks 5 ~ 28 as Tie Line (LK6).
