Issue 2.0

5-26 Network Design Considerations

Table 5-3 IP Precedence and Diffserv Values Comparison

DSCP

Decimal

DSCP

Binary

IP Precedence Description

0 000000 0 Class Selector 0

1 000001

2 000010

3 000011

4 000100

5 000101

6 000110

7 000111

8 001000 1 Class Selector 1

9 001001

10 001010 AF11 (Assured Forwarding)

11 001011

12 001100 AF12 (Assured Forwarding)

13 001101

14 001110 AF13 (Assured Forwarding)

15 001111

16 010000 2 Class Selector 2

17 010001

18 010010 AF21 (Assured Forwarding)

19 010011

20 010100 AF22 (Assured Forwarding)

21 010101

22 010110 AF23 (Assured Forwarding)

23 010111

24 011000 3 Class Selector 3

25 011001

26 011010 AF31 (Assured Forwarding)

27 011011

28 011100 AF32 (Assured Forwarding)
