Issue 2.0
SV9100 Networking Manual 5-37
3.1.9 Tandem Connections
This example shows Tandem connections assignments made for systems A
and B.
Figure 5-12 TEL 302 (SIP MLT) makes call to TEL 202 (SIP MLT) via IP
K-CCIS illustrates calls between two SIP multiline terminals over IP-CCIS.
System A System B
Program 14-01-13
Trunk to Trunk Transfer
0 = Disable
1 = Enable (Default)
Program 14-01-13
Trunk to Trunk Transfer
0 = Disable
1 = Enable (Default)
Program 14-01-24
Trunk to Trunk Outgoing Caller ID Through
Mode
0 = Disable (Off) (Default)
1 = Enable (On)
Program 14-01-24
Trunk to Trunk Outgoing Caller ID Through
Mode
0 = Disable (Off) (Default)
1 = Enable (On)
Figure 5-12 TEL 302 (SIP MLT) makes call to TEL 202 (SIP MLT) via IP K-CCIS
IP Network
System
TEL 202
RTP/Control
TEL 201TEL 200
TEL 302TEL 301TEL 300
System
RTP/Control
