Issue 2.0

SV9100 Networking Manual 8-67

2. Same as Plug and Play mode.

3. Same as Plug and Play mode.

4. To enable key data and other station feature programming before IP

Phone is brought online, the extensions must be identified as IP

Phones. Once checked in the IP Phone List in PC-Pro (see images

below), the extensions are available for selection in Program 15 and

other station related Programs.

Figure 8-39 PCPro Programming Unregistered Phones

Figure 8-40 IP Phone List
