10-42 SV9100 NetLink
Primary System
Secondary System 1 Connected First
Secondary System 2 Connected Second
As described above, port assignment is performed in the order which the
communication server connects. With this condition, if a GCD-4COT is installed to
the Communication Server 1
– slot 5, the trunk ports are from 25 to 28. To predefine
the slots (and not have them automatically assigned by the communication server),
use PCPro.
SECTION 14 SLOT CONTROL
When performing a Remote Upgrade, you must connect to each individual system in
a NetLink Network. A Remote Upgrade to the Primary System does not upgrade the
Secondary Systems.
In the NetLink, the Primary System needs to control all the slots of the Secondary
Systems. For the Primary System to handle more slots, there is a Virtual Slot
Function in NetLink.
Slot
GCD-CP10
Slot
GCD-DLCA Ext port: 1 16
Slot
GCD-4COT Trunk port: 1 4
Slot
GCD-4PRTA Trunk port: 5 12
Slot
GCD-CP10
Slot
GCD-16DLCA Ext port: 17 32
Slot
GCD-8LCA Ext port: 33 40
Slot
GCD-4PRTA Trunk port: 13 20
Slot 5
Slot
GCD-CP10
Slot
GCD-16DLCA Ext port: 41 56
Slot
GCD-2BRIA Trunk port: 21 24
