Issue 2.0
5-16 SV9100 IP K-CCIS
Bandwidth Calculation
( [ Layer 2 overhead + IP/UDP/RTP header + Voice Payload ] / Voice
Payload ) * Default CODEC speed = Total Bandwidth
Example of a G.711 call over Ethernet using a 20 ms packet size and not
using RTP header compression
(.020 * 64000) / 8 = 160 Bytes for Voice Payload
( [ 18 + 40 + 160] / 160 ) * 64000 = 87200 bps
If VAD is not enabled, each side of the conversation would be streaming
87.2 Kbps in one direction for a total of 174.4 kbps.
Below is a chart showing the supported CODECs, with a few different
packet sizes over PPP and Ethernet.
CODEC Packet Size PPP Ethernet
G.711 10 103.2 kbps 110.4 kbps
G.711 20 83.6 kbps 87.2 kbps
G.711 30 77.1 kbps 79.5 kbps
G.711 40 73.9 kbps 75.6 kbps
G.722 10 103.2 kbps 110.4 kbps
G.722 20 83.6 kbps 87.2 kbps
G.722 30 77.1 kbps 79.5 kbps
G.722 40 73.9 kbps 75.6 kbps
G.729 10 47.2 kbps 54.4 kbps
G.729 20 27.6 kbps 31.2 kbps
G.729 30 21.1 kbps 23.5 kbps
G.729 40 17.8 kbps 19.6 kbps
G.729 50 15.9 kbps 17.3 kbps
G.729 60 14.5 kbps 15.7 kbps
G.726 10 71.2 kbps 78.4 kbps
G.726 20 51.6 kbps 55.2 kbps
