 Each system has 16 multiline terminals.
 Each system has eight analog trunks.
Assume that the systems were defaulted (first power on) with the following
cards installed as described below.
Card Interface Slot Assignment (PRG 10-03)
SYSTEM A
Slot
Card Type During 1st
Power On
Card Type And Ports
Card Type Ports
1
ESI(8)-U10 ETU ESI(8)-U10 ETU Station 1 ~ 8
2
ESI(8)-U10 ETU ESI(8)-U10 ETU Station 9 ~ 16
3
None None N/A
4
COI(8)-U10 ETU COI(8)-U10 ETU Trunks 1 ~ 8
5
DTI-U( ) ETU DTI-U( ) ETU Trunks 9 ~ 32
6
CCH(4)-U( ) ETU CCH(4)-U( ) ETU N/A
7
None None N/A
8
None None N/A
0A
None None N/A
System B
Slot
Card Type During 1st
Power On
Card Type And Ports
Card Type Ports
1
GCD-CP10 with GPZ-IPLE
Blade/Daughter Board
GCD-CP10 with GPZ-IPLE
Blade/Daughter Board
Trunks 29 ~ 52
2
GCD-8DLCA Blade GCD-8DLCA Blade Station 1 ~ 8
3
GCD-8DLCA Blade GCD-8DLCA Blade Station 9 ~ 16
4
None None N/A
5
GCD-4COTC Blade GCD-4COTC Blade Trunks 1 ~ 4
6
GCD-CCTA Blade GCD-CCTA Blade Trunks 5 ~ 28
