NEC Univerge SV9100 - Page 296

Issue 2.0
4-32 Programming
Description
Use Program 15-05 : IP Telephone Terminal Basic Data Setup to set up the basic
settings for an IP telephone.
Program 20 : System Option Setup
15-05 : IP Telephone Terminal Basic Data Setup
Level:
IN
Input Data
Extension Number Maximum eight digits
Item
No.
Item Input Data Default Description
Related
Program
01
Terminal Type
1 = H.323
2 = SIP
3 = None
4 = DT800/DT700
3
Viewing Only – No changes
permitted
02
Terminal MAC
Address
MAC address
00-00-00-00-00-00 to
FF-FF-FF-FF-FF-FF
00-00-00-00-00-00
MAC Address of registered
MLT SIP phone is stored
and/or can input the MAC
address of an MLT SIP
phone so when it comes
online it will be provided with
the extension in which the
MAC address matches.
15-05-01
04
Nickname
Up to 48 characters
No setting
Nickname section on Invite
message.
07
Using IP
Address
0.0.0.0~255.255.255.255
0.0.0.0
Informational Only
registered IP Phones
15-05-01
09
Call Procedure
Port
0 ~ 65535
0
11
DT800/DT700
C/CTR Port
0 ~ 65535
0
15
CODEC Type
1-Type 1
2-Type 2
3-Type 3
4-Type 4
5-Type 5
1
Assign the CODEC Type of
the MLT SIP.
84-24-XX
16
Authentication
Password
Up to 24 characters
None
Assign the authentication
password for SIP single line
telephones.
15-05-01
