Issue 2.0
SV9100 Networking Manual 4-39
Description
Use Program 84-10 : ToS Setup to set up the Type of Service data.
Program 84 : Hardware Setup for VoIP
84-10 : ToS Setup
Level:
IN
Input Data
Protocol Type 1 = Not Used
2 = Not Used
3 = Voice Control
4 = H.323
5 = RTP/RTCP
6 = SIP
7 = CCISoIP
8 = SIP MLT
9 = SIP Trunk
10 = Net-Link
11 = Video RTP/RTCP
Item
No.
Item Input Data Default Description
01
ToS Mode
0 = Disable (Invalid)
1 = IP Precedence
2 = Diffserv
0
When Input Data is set to 1,
Item No. 07 is invalid.
When Data is set to 2, Item
No. 02 ~ 06 are invalid.
02
Priority, IP Precedence
0~7
0 = Low
7 = High
0
1 = Router queuing priority
03
Low Delay
0~1
0 = Normal Delay, Low
Delay
0
1 = Optimize for low delay
routing
04
Wideband
(Throughout)
0~1
0 = Normal Throughput
1 = High Throughput
0
1 = Optimize for high
bandwidth routing
05
High Reliability
0~1
0 = Normal Reliability
1 = Low Reliability
0
1 = Optimize for reliability
routing
07
Priority (D.S.C.P. -
Differentiated Services
Code Point)
0~63
0
DSCP (Differentiated
Services Code Point)
