Issue 2.0
SV9100 Networking Manual 4-41
Description
Use Program 84-21 : CCIS over IP CODEC Information Basic Setup to set the
CODEC parameters of the GPZ-IPLE.
Program 84 : Hardware Setup for VoIP
84-21 : CCIS over IP CODEC Information Basic Setup
Level:
IN
Input Data
Item
No.
Item Input Data Default
01
Number of G.711 Audio Frames
1~4
1 = 10ms
2 = 20ms
3 = 30ms
4 = 40ms
3
02
G.711 Typ e
0 = A-law
1 = -law
0
03
G.711 Voice Activity Detection Mode
0 = Disable
1 = Enable
0
04
G.711 Jitter Buffer (min)
0~300ms
30
05
G.711 Jitter Buffer (average)
0~300ms
60
06
G.711 Jitter Buffer (max)
0~300ms
120
07
G.729 Audio Frame Number
1~6
1 = 10ms
2 = 20ms
3 = 30ms
4 = 40ms
5 = 50ms
6 = 60ms
3
08
G.729 Voice Activity Detection Mode
0 = Disable
1 = Enable
0
09
G.729 Jitter Buffer (min)
0~300ms
30
10
G729 Jitter Buffer (average)
0~300ms
60
11
G729 Jitter Buffer (max)
0~300ms
120
