Issue 2.0
4-44 Programming
Description
Use Program 84-33 : Fax Over IP Setup to set up the parameters of the Fax Over
IP function.
Program 84 : Hardware Setup for VoIP
84-33: Fax Over IP Setup
Level:
IN
Index 1
Type 1 = H.323 Trunk
2 = Networking
3 = SIP Trunk
4 = SIP Extension
5 = CCIS over IP
6 = NetLink
Input Data
Item
No.
Item Input Data Default Profile 1 Profile 2
01
FAX Relay Mode
0 = Disable
1 = Enable
2 = Each Port Mode
0
02
T.38 Protocol Mode
1 = R/U
2 = U/R
3 = RTP
4 = UDPTL
1
04
Jitter Buffer (max)
0 ~ 300
160
05
T.38 RTP Format Payload
Number
96 ~ 127
100
06
T.38 Fax Maximum Speed
0 = V.27ter, 4800bps
1 = V.29, 9600bps
2 = V.17, 14400bps
2
07
T.38 Data Error Correction Mode
0 = Redundancy
1 = FEC
0
08
T.38 Error protection depth for
Signaling
0 ~ 2
0
09
T.38 Error protection depth for
Data
0 ~ 2
0
