Issue 2.0

SV9100 Networking Manual 8-11

Programming - GCD-CP10:

10-12-01 : GCD-CP10 Network Setup - IP Address (for GCD-CP10)

10-12-10 : GCD-CP10 Network Setup - Subnet Mask

10-12-03 : GCD-CP10 Network Setup - Default Gateway

10-12-09 : GCD-CP10 Network Setup - IP Address

(This assignment is for GCD-CP10 when the GPZ-IPLE daughter board is

installed.)

10-13-01 : In-DHCP Server Setup - DHCP Server Mode

10-14-01 : Managed Network Setup

10-14-02: Managed Network Setup

10-16-16: SIP Server Address

10-16-27: SIP Server Port

0.0.0.0

255.255.255.0

192.168.1.254

192.168.1.20

Enable

192.168.1.200 Min

192.168.1.250 Max

192.168.1.20

5080

Programming - GPZ-IPLE:

84-26-01 : IPL Basic Setup - IP Address 192.168.1.21

Programming - IP Phones:

DHCP Mode (Ext. 200): Enabled
