Issue 2.0

SV9100 Networking Manual 8-25

IMPORTANT

Below is an example of this setup.

This is just an example, you must enter your own local information.

Enter the IP Address of the TFTP

server that the IP Phone Firmware

is stored on.

If using FTP, change the server

mode to FTP and enter the proper

IP Address and login name/

password.
