Issue 2.0
8-74 IP Multiline Station (SIP)
Override is not supported in a SV9100 system that had a 3rd Party CTI
connection to the CPU (i.e., UC Suites Apps Shared Services, UCB), or to a
terminal with a 1st Party CTI connection (i.e., PC Assistant/Attendant and
Softphone or 1st Party TAPI driver), and would show Rejected Override >>>CTI
Link... in the display.
Override with CTI is supported on a per station basis using Program 15-05-39
with certain restrictions.
When using Override with an active CTI connection, Program 15-05-39 must be
enabled for the extensions that will be overridden. The overriding terminal must
be of the same type and number of line keys as the terminal to be overridden. If
the types of terminals and number of keys are different between overriding and
overridden phones, the Telephony Service Providers (1st Party and 3rd Party)
may not function properly.
Table 8-3 IP Phone Relocation
Program/Item
No.
Description/
Selection
Assigned Data Comments
10-46-01
DT800/DT700 Server
Information Setup – Register
Mode
0 = Normal
1 = Auto
2 = Manual
Default is 0
Set up the information of the SIP
Multiline (DT800/DT700 series) Server.
This PRG is a system-wide setting.
15-05-27
IP Telephone Basic Setup –
Personal ID Index
0~960
0
Default is 0
Used when the SIP Multiline telephone
is using manual/
auto registration. Assign each phone a
unique personal index. Then go to
command 84-22 to assign
the user name and
password.
84-22-01
DT800/DT700 Multiline
Logon Information Setup –
User ID
Up to 32 characters
Default not assigned
Input the User ID when using manual or
auto
registration (Program 10-46-01).
84-22-02
DT800/DT700 Multiline
Logon Information Setup –
Password
Up to 16 characters
Default not assigned
Input the Password when using manual
or
auto registration (program 10-46-01).
84-22-04
DT800/DT700 Multiline
Logon Information Setup –
Log Off
0 = Off
1 = On
Default is 1
Input the Personal ID from terminal
automatically when log on again.
If set to 0, IP Phone Relocation fails.
