Issue 2.0

SV9100 Networking Manual 10-15

Primary

MOH MOH

Secondary

Hold

When a terminal is placed on hold, MOH comes from the

communications server in which the terminal resides.

Primary

MOH MOH

Secondary

Hold

Trunk

When a terminal is placed on hold, MOH comes from the

communications server in which the terminal resides.
