Issue 2.0

1-18 General Information <US Only>

Figure 1-16 Closed Numbering Plan Example

28 00

Office Location (Access Code

analyzed by Program 44-02-01)

Station Number

When a call is originated from Office A to Office C, 2800 is dialed.

 When using a Closed Numbering Plan, the station numbers can have two to

eight digits.

2800 280121012100

25012500

KTS A

KTS C

KTS B
