Issue 2.0
SV9100 Networking Manual 10-39
51-16-06 : NetLink System Data Replication Mode Setting – System Data
Replication Interval
Set the time to start replication to the next node after replication has completed
to one node (1~86400 seconds).
SECTION 9 CREATE RECOVERY DATABASE
Before assigning a System ID, you should create a Recovery Database. The
Recovery Database can be used when you want to disconnect the communication
server from the NetLink.
Related Programming:
90-57-01 : Backup Recovery Data
Back up the SV9100 data file preserved in the flash memory on the CCPU. This
data is used for recovering data if required. Up to five recovery files can be
preserved in the flash memory on the CCPU.
90-58-01 : Restore Recovery Data
If required, use this option to restore one Backup Recovery Data file (files 1-5,
saved in Program 90-57-01) to restore the previous SV9100 data. After executing
this option, the SV9100 restarts automatically.
90-59-01 : Delete Recovery Data
Delete the Backup Recovery Data files (files 1~5, saved in Program 90-57-01), if
needed.
SECTION 10 LICENSING CONTROL
For the NetLink feature, a license with an activation code is required. This license
determines how many communication servers can be connected.
All licenses for all options (applications, adapters, ports, etc.) must be registered in
the Primary System.
The VoIP Channel for each Secondary must be licensed in PRG 10-54 in the Primary
System.
When Fail-Over occurs:
The Primary System gives a copy of the activation codes to the Secondary Systems.
This allows the features to continue even if the Primary System fails and a
Secondary System becomes the new Primary System.
Communication server reset is required.
