Issue 2.0

SV9100 Networking Manual 10-83

Description

Use Program 51-19: NetLink IP Trunk (SIP) Calling Party Number Setup for

Extension to set CPN transmission for each secondary system.

Conditions

None

Feature Cross Reference

None

Program 51 : NetLink Service

51-19 : NetLink IP Trunk (SIP) Calling Party Number Setup for Extension

Level:

Input Data

Item

No.

Item Input Data Default

NetLink CPN Transmission

This program assigns transmission of Calling

Party Number (CPN) from PRG 21-19 for each

secondary system. The transmission applies for

every extension.

0 = Disable

1 = Enable
