NEC Univerge SV9100 - Page 577

Issue 2.0
11-4 NAPT
WAN Settings: 0. Config/ 2. SIP Settings/ 8. NAT Traversal/ 3. WAN
Settings [Eco, Value, Sophisticated]
Self Port Settings: 0. Config/ 1. Network Settings/ 6. Advanced Settings/ 5.
Self Port Settings [Eco, Value, Sophisticated]
Number and
Name of
Setting
Setting
Value
Default
Value
Factory
Value
Auto
Config
Description
1. WAN Mate
IP Address
IP Address 0.0.0.0 Available Available WAN Address of the router that
the SV9100 resides behind. This
setting must match what is
programmed in PRG 10-12-07.
2. WAN SIP
Mate Port
1024~6553
5
5060 Available Available Port number the SV9100 uses for
SIP registration in PRG 10-46-
06.
3. WAN Self
IP Address
IP Address 0.0.0.0 Available Available Only used when Static NAT is
enabled.
This setting is the WAN address
of the router that the NAPT
Terminal resides behind.
Number
and Name
of Setting
Setting Value
Default
Value
Factory
Value
Auto Config Description
1. RTP Self
Port
1024~65528
(Even
numbers
only)
3462 Available Not available The number of the port
receiving RTP data.
Note: At default this is
assigned to port 3462. The
first IP phone on this local
LAN can use this port. The
second IP phone would need
to be changed to port 3464.
2. SIP Self
Port
1024~65535 5060 Available Not available The number of the port
receiving SIP data.
Note:At default this is
assigned to port 5060. The
first IP phone on this local
LAN can use this port. The
second IP phone would need
to be changed to port 5062.
