Issue 2.0

SV9100 Networking Manual 12-3

SECTION 3 RELATED FEATURES

 IP Multiline Station (SIP)

 IP Trunk – (SIP) Session Initiation Protocol

 K-CCIS – IP

 SV9100 NetLink

SECTION 4 GUIDE TO FEATURE PROGRAMMING

Program

Number

Program Name Description/Comments Assigned Data

Level

1 2 3

20-13-52 VoIP All DSP Busy Display Set on a per station class of

service basis, whether the “All

DSP Busy” alarm displays on the

LCD when the caller makes an IP

call and there is no VoIP DSP

resource.

0 = Off

1 = On

(default = 1)



90-10-01 System Alarm Setup Alarm Number 68 is used for All

DSP Busy.

0 = Not set

1 = Major

2 = Minor

(default = 2)


