Issue 2.0
SV9100 Networking Manual 13-61
02
Logical Port Number (B1)
0 = Not set
1 = Multiline Terminal (1~960)
2 = SLT Adapter (1~960)
3 = Bluetooth Cordless Handset (BCH) (1~960)
6 =
PGD(2)-U13 (Paging) (1~8)
7 =
PGD(2)-U13 (for Tone Ringer) (1~8)
8 =
PGD(2)-U13 (for Door Box) (1~8)
9 =
PGD(2)-U13 (for ACI) (1~96)
10 = DSS (1~32)
11 = --- Not Used ---
0
03
--- Not Used ---
04
--- Not Used ---
05
--- Not Used ---
B-Channel 2
Item
No.
Item Input Data Default
06
Terminal Type (B2)
0 =Not set
6=
PGD(2)-U13 (Paging)
7=
PGD(2)-U13 (Tone Ringer)
8=
PGD(2)-U13 (Door Box)
9=
PGD(2)-U13 (ACI)
12 =APR (B2 Mode)
0
07
Logical Port Number (B2)
0 =Not set
6=
PGD(2)-U13 (Ext. Speaker)
7=
PGD(2)-U13 (Paging/Tone Ringer) =
(1~8)
8=
PGD(2)-U13 (for Door Box) = (1~8)
9=
PGD(2)-U13 (ACI) = (1~96)
12 =APR (for B2 mode) (193~512)
0
08
Multiline Telephone Type
0=DT3**
1=DT4**
0
09
Side Option Information
0 =No option
1 =8LK Unit
2 =16LK Unit
3 =24ADM
0
Item
No.
Item Input Data Default
To Next Page
