Issue 2.0

13-74 AspireNet

Description

Use Program 10-19 : VoIP DSP Resource Selection to define the criteria for each DSP resource on

the VoIP blade.

Conditions

None

Feature Cross Reference

None

Program 10 : System Configuration Setup

10-19 : VoIP DSP Resource Selection

Level:

Input Data

Slot Number 1

Input Data

DSP Resource Number 01~256

Input Data

Item

No.

Item Input Data Default

VoIP DSP Resource Selection

0 = Common use for both IP

extensions and trunks

1 = IP Extension

2 = SIP Trunk

3 = Networking(CCIS)

4 = Use for NetLink

5 = Blocked

6 = Common without Unicast

Paging

7 = Multicast Paging

8 = Unicast Paging

Resource 1~256 = 0
