Issue 2.0

SV9100 Networking Manual 13-163

Description

Use Program 84-26 : IPL Basic Setup to set the IP address of IPL and the port.

Conditions

None

Feature Cross Reference

 Voice Over Internet Protocol (VoIP)

Program 84 : Hardware Setup for VoIP

84-26 : IPL Basic Setup

Level:

Input Data

Slot Number 1

Item

No.

Item Input Data Default

IP Address

xxx.xxx.xxx.xxx

Slot 1 = 172.16.0.20

RTP Port Number

0~65534

VoIP GW1 = 10020

RTCP Port Number

(RTP Port Number +1)

0~65534

VoIP GW1 = 10021

Video RTP Port

Sets the starting RTP port used by

standard SIP terminal video.

0 ~ 65534

20020

Video RTCP Port

Sets the starting RTCP port used by

standard SIP terminal video.

0 ~ 65534

20021
