Section 2 NS Series Functions 2-12 Display and Input Objects
2-261
NS Series Programming Manual
N
N
N
o
o
o
t
t
t
e
e
e
♦
Specify a file name of up to 12 characters (8 file name characters and 3 file extension characters).
The following characters can be used in file names. Full-size characters cannot be used.
Alphanumeric characters, underscore (_), dollar sign ($), and periods (.).
An error message will be displayed if illegal characters are used in a file name. If an error message
appears, re-enter the file name using permissible characters.
♦
There are no restrictions on the number of characters or lines that can be set to a LST file, but the
number of characters and lines that are set should match the settings under List size. Any charac-
ters or lines over the settings under List size will be ignored.
Example: 10 characters per line
When ABCDEFGHIJKLMN (14 characters) is set to the first line in the LST file, the display will be
ABCDEFGHIJ when the first line is displayed. The 11
th
and subsequent characters will be ignored.
♦
Click the Edit Button to open the text editor and, if creating a new LST file, save the file with LST as
the extension. Refer to the manual for the text editor you are using for information on methods for
saving files.
Some text editors automatically set TXT as the file extension. In such cases, use Explorer to
change the extension to LST.
♦
If ASCII is set in string displays, the following character codes will be used by the PT depending on
the system language that has been set.
System language Character display
Example
(character code B5)
Japanese Shift-JIS code
Chinese (traditional or sim-
plified)
GB2312 code Nothing is displayed be-
cause there are no corre-
sponding characters.
Other Latin 1code
µ
If the list data is specified to be held in a file, the language of the file and the system language must
be the same (e.g., Japanese or English).
♦
The address storing the text string for the selected list will be cleared if screens are switched with
Switching screens with Store the Selected Line No. in the Specified Address or Store the String of
the Selected Line in the Specified Address while either Switch Display Block or Support Display Start
Line Switching is set for external control will clear.
If the text string for a selected list will be used again after the screens are switched, use the ladder
program or other host program to store text string data before switching the screens.
♦
The data format (BCD or binary) for the Address for Specifying the File Line on the General Tab
Page, Store the Selected Line No. in Specified Address on the Selection Tab Page, and Address for
Switching the Display Block and Address for Switching the Display Start Line on the External Control
Tab Page is set by selecting Project Properties
from the PT Menu and using the Data Format Tab
Page.
Text Tab Page
Sets the text attributes, such as font and color, for the display string. Refer to Text Attributes under 2-8
Common Functional Object Functions for details.
Background Tab Page
Sets the background color for the functional object from a selection of 256 colors. Refer to Background
and Setting Colors under 2-8 Common Functional Object Functions for details.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
