Section 2 NS Series Functions 2-13 Display
2-273
NS Series Programming Manual
No. Setting Details
1 Indirect
Reference of
String
Normally displays the string as fixed characters. When specifying a raster font, it is
also possible to select Indirect reference of string and browse for the file containing
the string to display.
File Name Specifies the file where the string to be displayed is stored. Only files with the exten-
sion .txt can be specified.
The file must be stored in the folder where the projects are stored.
Click the Browse Button to specify a string file in any directory.
The specified string file will be automatically copied to the folder where the screen
files are stored. Use this copied file for any subsequent editing.
The file specifications are given below.
File name: 8 file name characters + .txt (extension)
Alphanumeric characters, underscore (_), dollar signs ($), and periods (.).
Editing software: Text editor
No. of lines:
32,767
No. of characters
per line: Up to 64
Text object 1
Text object 2
Text object 3
•
•
•
•
Address for
Specifying File
Line
Address for Selecting a Line
$W100 1
Specifies first line.
Text object
Motor 0
Displays the string in
the first line.
Text file
1
st
line Motor 0
2
nd
line Motor 1
3
rd
line Motor 2
••
••
••
The previously displayed string will remain if the file line specification address contents
change to 0. The display will be cleared when the contents change to 0 if the Clear
display when address value is 0 checkbox is selected.
Character
code
Specify the character code as multibyte or Unicode. Multibyte code uses one byte for
half-width characters and two bytes for full-width characters. Unicode uses two bytes
for all characters.
2 Refer to the
Character
String Table
Select this checkbox to select a label string from the strings registered in the charac-
ter string table.
