Section 2 NS Series Functions 2-13 Display
2-274
NS Series Programming Manual
N
N
N
o
o
o
t
t
t
e
e
e
♦
If vector fonts are specified for label strings, the string and character color cannot be specified indi-
rectly.
♦
Up to 32,767 lines can be set but this may depend on the text editor being used.
♦
If ASCII is set in text, the following character codes will be used by the PT depending on the system
language that has been set.
System language Character display Example
(character code B5)
Japanese Shift-JIS code
Chinese (traditional or simpli-
fied)
GB2312 code Nothing is displayed be-
cause there are no corre-
sponding characters.
Other Latin 1code
µ
♦
Character codes for indirectly specified text strings are used to handle other languages. Refer to
Multi-Language Display in the CX-Designer Online Help for details on using other languages.
♦
To set the data type (BCD or binary) for the address for specifying the File Line, select Project
Properties from the PT Menu and set the data type on the Data Type Tab Page.
Referencing Strings from String Table
If referencing the string table for strings, the display string can be switched depending on the value at a
specified communications address.
1
No. Item Details
1 Indirect Select this checkbox to indirectly specify the display string number.
The value at the set communications address will be used as the
string number for displaying the label string. The contents of the
communications address is set as a binary value.
N
N
N
o
o
o
t
t
t
e
e
e
♦ The vector font cannot be used when referencing the string table for label strings.
To Next Page
