Section 2 NS Series Functions 2-17 Data Blocks
2-392
NS Series Programming Manual
N
N
N
o
o
o
t
t
t
e
e
e
♦
The number of fields displayed in the data block table is determined by widths of the object and
fields. If all fields will not fit in the data block table, they can be displayed by using the horizontal
scroll bar.
Text Tab Page
Sets the text attributes (font, color, etc for the numeral values and character strings. Refer to 2-8
Common Functional Object Functions – Text Attributes for details.
N
N
N
o
o
o
t
t
t
e
e
e
♦
The offset and display position set in the Field Label Setting Dialog Box will be reflected in nu-
meral field and string field. The horizontal position set on the Text Attribute Tab Page will not be
reflected.
Background Tab Page
Sets the background color of the object and the record color. To fill the record, click the Set Button to
display the Color Setting Dialog Box and select the color for the record.
1
5
2
3
4
Example:
2
3
4
5
1
The selected line is displayed in reverse video.
No. Item Details
1 Color of Top Column Sets background color of the column header.
2 All borders Sets entire border color.
3
Color of Odd Col-
umns
Sets background color of odd columns.
4
Color of Even Col-
umns
Sets background color of even columns.
5
Entire background
Color
Sets background color except for field label name and record data display areas.
Refer to 2-8-7 Setting Colors (Color/Shape Tab) for details on operating Color Setting Dialog Box.
