Section 2 NS Series Functions 2-17 Data Blocks
2-393
NS Series Programming Manual
Icon Tab Page
Sets whether an icon button is displayed at the bottom of object.
1
2
3
No. Item Details
1 Icon
Icon buttons that perform operations can be displayed at the bottom of the data block
object.
Read Data File
Reads data from the specified CSV data file, and displays it in the data block
table.
Write Data File
Overwrites data displaying from the data block table to the specified CSV data
file.
Read from the
address
Retrieves data from the addresses set in Field Setting Dialog Box to the records
selected on the data block.
Write to the
address
Writes data selecting in the data block to the addresses set in the Field Setting
Dialog Box.
Add the record Adds a new record below the selected record.
Delete the
record
Deletes the selected record.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
