Section 2 NS Series Functions 2-17 Data Blocks
2-394
NS Series Programming Manual
No. Item Contents
2 Options
Check the items for which to display confirmation messages when a process is per-
formed by pressing one of the icon buttons as described for number 1, above.
Display
confirmation
dialog box
when reading
data file.
When retrieving the CSV data file, the following dialog box is displayed. Click a button to
select the source (PT or Memory Card).
When this option is not set, data file will always be retrieved from the PT ("Hardware").
Display
confirmation
dialog box
when writing
data file.
When writing to the CSV Data File, the following dialog box is displayed. Click a button to
select the destination (PT or Memory Card).
When this option is not set, data will always be written to the PT ("Hardware").
Display
confirmation
dialog box
when reading
from the
address.
Display confirmation messages when executing the process.
Display
confirmation
dialog box
when writing
to the ad-
dress.
Display
confirmation
dialog box
when adding
to the record.
Display
confirmation
dialog box
when deleting
from the
record.
3 Icon Size Sets the horizontal and vertical dimensions of the icon. (16 to 48)
N
N
N
o
o
o
t
t
t
e
e
e
♦
The icon size and button size of the horizontal scroll bar are the same. When changing the icon
size, the button size of the horizontal scroll bar will be changed simultaneously.
♦
The confirmation dialog boxes (for reading/writing CSV data file) displayed in test mode and on
the PT are different. A Source/Destination Dialog Box is displayed on the PT, and a confirma-
tion dialog box is displayed in test mode.
PT Test Mode
To Next Page
