Oracle SuperCluster T5-8 User Manual

Connector Locations
■
SPARC T5-8 No. 2 (slot 18)
■
ZFS storage controllers (Figure 28, “ZFS Storage Controller,” on page 249):
■
ZFS storage controller No. 1 (slot 33)
■
ZFS storage controller No. 2 (slot 34)
■
Exadata Storage Servers (Figure 29, “Exadata Storage Server ,” on page 250):
■
Exadata Storage Server No. 1 (slot 2)
■
Exadata Storage Server No. 2 (slot 4)
■
Exadata Storage Server No. 3 (slot 6)
■
Exadata Storage Server No. 4 (slot 8)
■
Exadata Storage Server No. 5 (slot 35) (Full Rack only)
■
Exadata Storage Server No. 6 (slot 37) (Full Rack only)
■
Exadata Storage Server No. 7 (slot 39) (Full Rack only)
■
Exadata Storage Server No. 8 (slot 41) (Full Rack only)
■
The Ethernet Management Switch (Figure 30, “Ethernet Management Switch (Cisco
Catalyst 4948 Ethernet Switch) ,” on page 251)
■
PDU circuit breakers and AC sockets (Figure 31, “Circuit Breakers and AC Sockets on
the PDU,” on page 252)
FIGURE 24
Sun Datacenter InfiniBand Switch 36
Figure Legend
1
NET MGT 0 and NET MGT 1 ports
2
InfiniBand ports 0A-17A (upper ports)
3
InfiniBand ports 0B-17B (lower ports)
246 Oracle SuperCluster T5-8 Owner's Guide • May 2016
