Install a PCIe Card in PCIe Slot 1 or 2
110 Oracle Server X6-2 Service Manual • June 2016
b.
Disconnect the rear bracket that is attached to the PCIe card from the rear of
the PCIe riser.
3.
Place the PCIe card on an antistatic mat.
Caution - Whenever you remove a PCIe card, you should replace it with another PCIe card or
a PCIe filler panel. Installing PCIe filler panels in vacant PCIe slots helps reduce the level of
electromagnetic interference (EMI) emitted by the server. For instructions for installing a PCIe
filler panel, see “Removing and Installing Server Filler Panels ” on page 187.
Install a PCIe Card in PCIe Slot 1 or 2
Note - PCIe slot 1 is nonfunctional in single-processor systems.
1.
Retrieve the PCIe card and riser you want to install.
2.
Insert the rear bracket that is attached to the PCIe card into the PCIe riser.
