Install the Motherboard
Servicing FRUs 169
fasteners are located on the underside of the cover) are inside the load plate
(it does not matter which side), and use your thumb to press the other side
of the processor socket cover into the load plate. [3].
You will hear a clicking sound when the processor socket cover snaps into place.
c.
Close the processor ILM assembly load plate [4 and 5].
d.
Repeat Step a through Step c above to install the second processor socket
cover on the failed motherboard.
Related Information
■
“Install the Motherboard” on page 169
Install the Motherboard
Caution - The motherboard should be installed only by an Oracle qualified service technician.
1.
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 59.
2.
Insert the motherboard into the server chassis [1].
a.
Grasp the metal bracket located to the rear of the DIMMs and tilt the front of
the motherboard up slightly and push it into the opening in the rear of the
server chassis.
b.
Lower the motherboard into the server chassis and slide it to the rear until
it engages the seven mushroom-shaped standoffs located on the server
chassis under the motherboard.
